GLS 192 P

home / product categories / Complementary machines

V-cutting saw equipped with two blades for 45° cuts. Equipped with two vertical material clamping units as standard. Equipped with exhaust connectors for connection to an extraction system. Pulsed coolant system. Automatic cutting operation with foot switch control. Options: profile clamping system for special glazing beads; extraction system for residual pieces; roller conveyors; length stop and measuring systems; profile support blocks; blades; high performance cutting fluid; glazing bead measuring systems.

Estimate Request

Technical data

WORK AREA

Maximum cutting width (mm)

130

Maximum cutting height (mm)

44,5

Minimum profile length (mm)

240

DIMENSION AND WEIGHT

Length (mm)

510

Depth (mm)

1.050

Height (mm)

1.180

Weight (kg)

140

MOTORS

Three-phase asynchronous motors

Motors power (kW)

2 x 0,9

Motor speed 50 Hz (r.p.m.)

2.800

Motor speed 60 Hz (r.p.m.)

3.400

FUNCTIONS

Vertical vices

Additional clamps (optional)

Simultaneous cutting of 2 glazing beads

Simultaneous cutting of 4 glazing beads

Automatic cutting sequence

Operation by foot switch

Integrated suction socket for connection of a suction device

TOOLS

Blades type

Blade diameter (mm)

200

Blade diameter (45° beveled) (mm)

Blade bore (mm)

Blade speed - motor 50 Hz (r.p.m.)

2.800

Blade speed - motor 60 Hz (r.p.m.)

3.400

EQUIPMENT

Vertical clamping device

Glazing bead counterblock

Glass panel simulation

Manual measuring systems

Roller conveyor

Connecting plate roller conveyor / measuring system

Extraction socket DN100

Swarf exhauster

ELECTRICAL CONNECTION

Connected load (without swarf exhauster) (kW)

1,9

Maximum backup fuse 240V 60Hz (without swarf exhauster) (A)

Maximum backup fuse 400V 50Hz (without swarf exhauster) (A)

PNEUMATIC CONNECTION

Pressure (bar)

Hose connection

DN10

Compressed air consumption (7 bar) per working cycle (without spraying) (l)

CUTTING DIAGRAM

Included

Available

Snap-in interchangeable counterblocks

The counterblocks are very easy to change: a snap-in mechanism enables them to be changed without having to use any other tools.

Workpiece clamping system

The workpiece is clamped from above by means of clamps; thin profiles can also be clamped by GLS 192 from the bottom to avoid the risk of deformation and to ensure a greater cutting precision.

Cutting module

Glass stopper cuts are made by 2 cutting units, one set at 45° and the other at 135°. Each cutting unit is made up of 2 blades: the first actually cuts the glass stopper and the second, which has a smaller diameter, makes the cut in the glass stopper that is to house the gasket. This machine configuration enables 2/4 profiles to be inserted in the counterblocks so that 2/4 glass stoppers can be cut at the same time.

Connection to roller conveyors and stop gauges

Beside the cutting area there is a steel support for connecting the machine to an infeed roller conveyor or a stop gauge that ensures high positioning precision while cutting the glass stopper.
